| Model泡沫包裝熱熔機型號 | CF-HM-200 |
| Screw diameter螺桿直徑 | φ197 mm |
| Screw distance螺桿長度 | 150 mm |
| Screw speed螺桿速度 | 110 r/min |
| Capacity產量 | 100～120Kg/h |
| Screen hole diameter濾網孔徑 | 40mm |
| Extrusion center height擠出中心高度 | 326 mm |
| Motor power電機功率 | 15KW |
| Heating power加熱功率 | 3 zones total 10kw |
| Crusher motor power破碎電機功率 | 2.2kwx2 |
| Crusher blades quatity破碎刀片數量 | Twin screw 9sets+10sets |
| Crusher rotation speed破碎轉速 | 100r/m |
| Size L×W×H機器尺寸 | 2800×1580×1950 |
| Weight 重量 |
1400 Kg |
